2. A soft, flexible jacket protects the thin core. This cable is designed to eliminate EMI/RFI interference common with standard quality audio cables.
3. Main uses: audio, musical instruments, engineering and all types of information transmission.
|
Fiber optic core diameter
|
Φ1.0 mm | ||
| Fiber optic core material | pmma | ||
| Outer diameter | Φ4.0 | ||
| Outer material |
PE, PVC
|
||
| Outer color | Blue/Black/Grey/Red | ||
| Optical Fiber Attenuation | 180 dB/km | ||
| Incident angle | 60° | ||
| Tensile strength | ≤3.0dB(0~80N) | ||
| Bend radius | 5xcore Diameter | ||
| Working temperature |
-55°C~+85°C
|
||
